SFILES 2.0 - an extended text-based flowsheet representation

This tool contains functionality for the conversion between PFD-graphs/P&ID-graphs and SFILES 2.0 strings. In the paper, we describe the structure of the graphs, notation rules of the SFILES 2.0, and the conversion algorithm.

SFILES is a text-based notation for chemical process flowsheets. It was originally proposed by d’Anterroches [1] who was inspired by the text-based SMILES notation for molecules. The textbased format has several advantages compared to flowsheet images regarding the storage format, computational accessibility, and eventually for data analysis and processing. However, the original SFILES version cannot describe essential flowsheet configurations unambiguously, such as the distinction between top and bottom products. Neither is it capable of describing the control structure required for the safe and reliable operation of chemical processes. Also, there is no publicly available software for decoding or encoding chemical process topologies to SFILES. We propose the SFILES 2.0 with a complete description of the extended notation and naming conventions. Additionally, we provide open-source software for the automated conversion between flowsheet graphs and SFILES 2.0 strings. This way, we hope to encourage researchers and engineers to publish their flowsheet topologies as SFILES 2.0 strings. The ultimate goal is to set the standards for creating a FAIR database of chemical process flowsheets, which would be of great value for future data analysis and processing.

How do use the software?

This is the source code you can use.
