Lukas Schulze Balhorn publishes paper on flowsheet mining at PSE

We are glad to share that our PhD student Lukas Schulze Balhorn has just published his first conference paper on “Flowsheet Recognition using Deep Convolutional Neural Networks” at PSE 2021+.

Flowsheets are the most important building blocks to define and communicate the structure of chemical processes. Gaining access to large data sets of machine-readable chemical flowsheets could significantly enhance process synthesis through artificial intelligence. A large number of these flowsheets are publicly available in the scientific literature and patents but hidden among innumerable other figures. Therefore, an automatic program is needed to recognize flowsheets. In this paper, we present a deep convolutional neural network (CNN) that can identify flowsheets within images from literature. We use a transfer learning approach to initialize the CNN’s parameter. The CNN reaches an accuracy of 97.9% on an independent test set. The presented algorithm can be combined with publication mining algorithms to enable an autonomous flowsheet mining. This will eventually result in big chemical process databases.
